Kooltherm K103 vs Celotex PIR Floor Insulation: How Much Thicker, and How Much Cheaper?
Kingspan Kooltherm K103 and Celotex PIR boards are both rigid, foil-faced insulation boards used under screeds and between floor joists. The difference is the core. Kooltherm K103 is phenolic, with a thermal conductivity (λ) of 0.019 W/mK, while Celotex PIR boards (TB4000, GA4000 and XR4000, now sold as Sopratherm) are 0.022 W/mK. That means K103 insulates better per millimetre, so the question is how much thicker Celotex has to be, and whether the extra depth is worth the saving. (We also have a K103 vs Recticel Eurothane GP comparison.)
The short answer
- To match a K103 board at the lowest cost you need 5–35mm more Celotex PIR, depending on thickness (see the table).
- At the prices below, the matching Celotex board costs roughly 39–45% of the K103 price per m², a saving of £7.25–£32.70 per m² ex VAT. On a typical 50m² floor that is several hundred pounds saved, and over £1,000 at 100mm K103 and above.
- Choose K103 when floor height is tight, for example in a renovation with fixed door thresholds, stairs or an existing floor level to meet. Choose Celotex when you have a few extra millimetres to spare.
Free printable download: K103 vs Celotex comparison, one A4 page (PDF). Handy to keep in the van or on site.
K103 vs Celotex: thickness for the same R-value
R-value (thermal resistance) is thickness ÷ λ. If you use a board with the same or higher R-value, the rest of the floor build-up stays the same and the U-value will be the same or better. The table shows the cheapest Celotex board per m² that does that. Popular sizes such as 75mm, 100mm and 120mm often cost less per m² than the in-between sizes, so the best-value match is sometimes a little thicker.
| K103 | K103 R (m²K/W) | Cheapest Celotex match | Celotex R | Extra depth | K103 £/m² | Celotex £/m² | Saving £/m² |
|---|---|---|---|---|---|---|---|
| 25mm | 1.30 | 30mm | 1.35 | +5mm | £12.91 | £5.66 | £7.25 |
| 40mm | 2.10 | 50mm | 2.25 | +10mm | £17.08 | £7.30 | £9.77 |
| 50mm | 2.60 | 60mm | 2.70 | +10mm | £19.99 | £8.93 | £11.06 |
| 60mm | 3.15 | 75mm | 3.40 | +15mm | £23.74 | £9.85 | £13.89 |
| 70mm | 3.65 | 100mm | 4.50 | +30mm | £27.49 | £12.03 | £15.46 |
| 75mm | 3.90 | 100mm | 4.50 | +25mm | £29.57 | £12.03 | £17.54 |
| 90mm | 4.70 | 120mm | 5.45 | +30mm | £34.58 | £14.95 | £19.62 |
| 100mm | 5.25 | 120mm | 5.45 | +20mm | £37.91 | £14.95 | £22.95 |
| 120mm | 6.30 | 150mm | 6.80 | +30mm | £44.57 | £18.01 | £26.56 |
| 140mm | 7.35 | 75mm + 100mm (2 layers) | 7.90 | +35mm | £51.24 | £21.88 | £29.36 |
| 150mm | 7.85 | 75mm + 100mm (2 layers) | 7.90 | +25mm | £54.57 | £21.88 | £32.70 |
Prices correct at 16 October 2026, ex VAT; check the product pages for current prices. K103 is sold by the full pack, Celotex per 2.88m² sheet. The 30mm board is Celotex TB4000, 50mm to 100mm are GA4000 and 120mm and 150mm are XR4000. R-values are rounded down to the nearest 0.05 m²K/W. At 140mm and 150mm the Celotex match is laid in two layers (75mm + 100mm), because the thickest single board is 150mm.
Worked example: a 50m² floor
Say your floor needs K103 100mm (R 5.25). The cheapest Celotex equivalent is XR4000 120mm (R 5.45), which is 20mm thicker. Bought in whole packs or sheets for 50m², that is about £1,965 of K103 (6 packs of 3) against £775 of Celotex (18 sheets), a saving of about £1,190 ex VAT.
Celotex is delivered separately from our other products: £40 ex VAT under £550 ex VAT and free from £550 ex VAT, with a minimum Celotex order of £400 ex VAT. The example above is over £550, so delivery is free. We deliver to England only.
What the extra depth means on site
- Solid floors under screed: 5–35mm more insulation means digging deeper, using a thinner screed (within the screed’s minimum thickness) or accepting a higher finished floor.
- Suspended timber floors: boards fitted between joists usually have depth to spare, so Celotex is often the easy win here.
- Renovations: if raising the floor means trimming doors, altering thresholds or changing a stair riser, the extra work can outweigh the saving. That’s where K103 earns its price.
Check before you buy
- Work out the U-value for your actual floor with our free PIR U-value calculator, and see what thickness of PIR insulation do I need?. Confirm the final specification with your building control body or designer.
- Check each board’s datasheet and the Sopratherm BBA certificate (linked on the product pages) for compressive strength and loading, especially for heavily loaded floors.
- Use the insulation calculator to work out sheets or packs. Remember K103 comes in full packs only.
- Celotex is now sold as Sopratherm; the boards and codes are unchanged. Comparing Celotex with other PIR? See Kingspan TP10 vs Celotex XR4000.
